Total Weight1,000 kg

Maximum Load Capacity400 kg

Bucket Capacity0.25 m3

Fuel TypeLithium battery

Low-range Speed10 km/h

High-range Speed19 km/h

Wheel Configuration2/2 front/rear

Overall Size2,100 x 1,100 x 2,090 mm

Wheelbase1,340 mm

Track Width895 mm

Maximum Ground Clearance200 mm

Dumping Height1,800 mm

Battery Model60 V / 200 Ah

Battery TypeLithium iron phosphate

Battery Quantity12

Battery Capacity12.0 kWh

Rated Voltage60 V

Working Time10 h

Charge Time6.5 h

Hydraulic System Voltage12 V

Hydraulic Power3,000 W

Hydraulic Displacement10 ml/r

Hydraulic Rotating SpeedLow 500 r/min; high 1,800 r/min

Hydraulic Pressure16 MPa

Steering SystemHydraulic; 11 MPa

Power FormAlternating current

Motor Quantity2

Motor Power2.5 x 2 kW

Tires23 x 8.5-12 or 23 x 10.5-12

Working BrakeDrum oil brake

Parking BrakeDrum handbrake
