MG40D Site Dumper
MG40D is a site dumper supplied for reliable day-to-day work, practical operation and export-ready project support.
MG40D Equipment Overview
MG40D is a site dumper supplied for reliable day-to-day work, practical operation and export-ready project support. Contact MEGA with your required configuration, operating conditions and destination port for current technical information.
Product Gallery
Technical Information
Vehicle Size4,900 x 1,850 x 2,700 mm
Wheelbase2,500 mm
Total Weight3,200 kg
Drive TypeFour-wheel drive
Tires23.5/70-16
Drive AxleWheel-side axle
Engine4DW91-45
Engine Power36.8 kW
Gearbox265 high/low-speed gearbox
Travel Speed30 km/h
Maximum Gradeability<= 30 degrees
Minimum Turning Radius4,500 mm
Minimum Ground Clearance250 mm
Bucket Capacity1.6 m3
Tipping Bucket Rotation Angle+/- 90 degrees (optional)
Rated Load4,000 kg
