MG40TR Crawler Tractor
MG40TR is a crawler tractor supplied for reliable day-to-day work, practical operation and export-ready project support.
MG40TR Equipment Overview
MG40TR is a crawler tractor supplied for reliable day-to-day work, practical operation and export-ready project support. Contact MEGA with your required configuration, operating conditions and destination port for current technical information.
Product Gallery
Technical Information
Product Overview
MG40TR is configured for ploughing and rear-output implement work, with a PTO gearbox, hydraulic steering and rear hydraulic quick-coupler outlets shown in the source material.
Key Details
- TY8+8 PTO gearbox with shuttle shift.
- Carter 490 brand 50 hp engine in the configuration sheet.
- Rear PTO output is listed as 540-720, with hydraulic steering.
| Configuration | Transmission | TY8+8 PTO special gearbox with shuttle shift |
|---|---|---|
| Engine | Carter 490 brand engine, 50 hp | |
| Rear Tire | 11.2-24 | |
| Front Tire | 650-16 | |
| Rear Hydraulics | Two rear hydraulic quick coupler sets with multi-way valve, strong lift and forced lowering | |
| Counterweights | Two rear counterweights and four thickened front counterweights | |
| Rear PTO Output | 540-720 | |
| Steering | Hydraulic steering | |
| Nameplate Data | Product Type | Wheel Type Diesel Engine Tractor |
| Engine Model | HSQ4A25T-Z2 | |
| Engine Power | Huashen 36.8KW | |
| Rated Speed | 2400RPM | |
| Transmission | Gear type | |
| Operating Weight | 1600 KG | |
| Overall Size | 5.0*0.98*1.2M |
