MEGA Product Detail

MG7500B Self-Loading Concrete Mixer Truck

MG7500B is a self-loading concrete mixer truck supplied for reliable day-to-day work, practical operation and export-ready project support.

Request a Quote
View Product Range
MG7500B Self-Loading Concrete Mixer Truck

MG7500B Equipment Overview

MG7500B is a self-loading concrete mixer truck supplied for reliable day-to-day work, practical operation and export-ready project support. Contact MEGA with your required configuration, operating conditions and destination port for current technical information.

Product Gallery

MG7500B Self-Loading Concrete Mixer Truck view 2
MG7500B Self-Loading Concrete Mixer Truck view 3
MG7500B Self-Loading Concrete Mixer Truck view 4
MG7500B Self-Loading Concrete Mixer Truck view 5
MG7500B Self-Loading Concrete Mixer Truck view 6

Technical Information

Model7.5 m3 self-loading concrete mixer truck

Vehicle Size7,360 x 3,100 x 4,640 mm (lifting arm); 8,580 x 3,100 x 3,560 mm (drop arm)

Wheelbase3,200 mm

Track Width1,845 mm

Overall Weight12,500 kg

EngineYC6J125Z-T20

Power92 kW

Gearbox315 separate gearbox

Drive AxleFront 30S wet axle; rear 30 axle

Tires16/70 R22.5 double tires

Mixing Capacity7.5 m3

Reduction Ratio1:103

Mixing Speed>= 15 rpm

ReducerHL6F-B2700

Running Speed35 km/h

Traction Type4 x 4

Water Tank Capacity1,070 L

Diesel Tank Capacity180 L

Hydraulic Tank Capacity180 + 35 L

Discuss Your MG7500B Requirement

Send your application and target configuration to receive a current export quotation.
